Casing material for single cell

Aluminum shell

Nominal Voltage

3.2V

Capacity

50Ah

Core size

D32*W173*H127MM

Cell Weight

1.42KG

Charging Current

Standard Charging:0.2C

Max Charging:1.5C

Max Discharging Rate

Continuous Discharging:2C

Cut-off Voltage

Charging:3.65V

Discharging:2.5V

Internal Resistance

≤ 0.5mΩ (At 0.2C rate, 2.0V cut-off)

Working Temperature

Charging: -10°C~55°C

Discharging: -20°C~70°C

Storage Temperature

≤1month: -10–45°C

≤3month: 0–30°C

≤6month: 20±5°C

Life Cycle

>6000 times
